Name:QF-1 silicone sealant filling and capping machine
Number:Pro2012103082551
Related Products:QF-1 silicone sealant filling and capping machine
Label:QF-1 silicone sealant filling and capping machine
Company:qunxing machinery
Time:2012/10/30 8:28:50

   QF-1 silicone sealant hydraulic pressure racking machine is our major product, special designed hydraulic pressure ejection of compact racking machine. It suits for silicone sealant manufacturers to fill and pack. Besides filling plastic bottles,it can be also used in the filling and packing of aluminum tubes and bag-packaged grease lubricant. This equipment features rational structure, easy operation steady and reliable for use.


model
QF-1
Hydraulic pressure station model
YG—4KB—E
Diameter and trip of hydraulic cylinder
Φ150×1050mm
Applicable adhesive cement
Acidic and litmusless silicone sealant
Packing container
310ml plastic bottles, aluminous soft bags and aluminous tubes.
Tube transmission path
Dg65
Electrical power
4Kw
Lubropump model
10M4Y
The form of quantitative control
Sensor and digital control
Voltage
380V-50~60Hz
Platen-diameter and sealed form
Φ570mm,O-dingqing cushion rubber
The original barrels’ specifications
200LRound directed edge big mouth metal pail
The scope and accuracy of packaging
60~450g±3g
Filling capacity
~180Kg/h
The control way to plunge bottom blug
Manual control or autocontrol
Subpackage mouth and station of plunge plug
Each 1
Platen up and down operation
Push-button by manual to control electromagnetic valve
Work pressure (Mpa)
0.7(take charge by customers)
Transportation length of tube (mm)
2000
Maximum shape size (mm)
Hydraulic host:950×800×2650
Hydraulic station:800×700×850
Working table:1050×680×1300
Whole weight of the machine
1050 Kg
